Product Details
Product Description
| Interface | 32*40G/100G Base-X QSFP28 | System Management | Supports CLI based on RS232 serial port, Telnet and SSHv2 Supports WEB-based configuration operation management, supports SNMP V1/V2/V3 Supports remote upgrade or device management via FTP and TFTP |
| Environment Temperature | Operating Temperature: -10°C～50°C Storage Temperature: -40°C～70°C Relative Humidity: 5%～95%, non-condensing |
Power Supply | AC: 100～240V 47/63Hz DC: -20V~-60V |
| Dimension & Weight | 440*410*44mm(L*W*H) | Power Consumption | Full Load≤500W |
Key Feature
32*40G/100G Base-X QSFP28
Support Combine the processing power of multiple switches into a single logical device.
Support When a switch in the stack system fails, traffic can be automatically switched to other switches, network availability and redundancy
Support Stacking simplifies the management process. Administrators only need to manage one logical device
Provides exceptional high-bandwidth connectivity for modern network demands, supporting up to 100G speeds per port
Supports both AC and DC power supply configurations with hot-swappable power modules to ensure high availability and reliability in mission-critical environments
Support port speed and flow speed limit function Support classification based on service flow and Qos flow control function
Support queue scheduling algorithms such as SP/WRR/SP+WRR
Support remote user authentication based on Tacacs+, Radius, and Local user authentication
Support CLI based on RS232 serial port, Telnet and SSHv2
Support WEB-based configure operation management, support SNMP V1/V2/V3
Support remote upgrade or equipment through FTP and TFTP
| Model | Description |
| S6670-32QC | 32*40G/100G Base-X QSFP28 |
| Dual Power For Option, AC+AC/AC+DC/DC+DC | |
| CN / EU / USA Plug Optional |
